025CKG Контроллер Dell PERC H830 PCIe RAID Storage 025CKG ()
025CKG Контроллер Dell PERC H830 PCIe RAID Storage 025CKG ()
Description:Dell PERC H830 2GB PCIe 3.0 x8 RAID Storage Controller CardFor Dell PowerEdge C4130 FC430 FC630 FC830 R230 R230XL R330 R330XL R230 R230XL R330 R330XL R430 R530 R530XD R630 R730 R730XD R830 R930 T130 T330 T330 T430 ServersPart Number(s)
Dell Part# 25CKG
Dell Part# 025CKGNote:Please confirm Low Profile or Full Height Bracket
In comments box at checkout. Thank you
Overview:
The PERC H830 RAID Controller offers expandable 2GB storage capacity to improve the performance of server systems. The double module channel provides high speed connectivity.
Specifications:
CategoryDell Controller
Sub-CategoryController
GenerationPCI-Express
Part Number025CKG
Products ID725607
Device TypeStorage Controller (RAID) Plug-In Card
Bus TypePCIe 3.0 x8
InterfaceSATA 6Gb/s/SAS 12Gb/s 36-pin 4x Mini SAS
Data Transfer Rate1200MB/s
Buffer Size2GB
Channel Qty8
Max Storage Device Qty255
RAID LevelRAID 0 1 5 6 10 50 60
Dimensons D x H16.76cm x 6.44cm
Max Operating Temperature55°_
Enlarge Image of Part# 025CKG
