46M0922 Контроллер IBM ServeRAID M5014 SAS/SATA 46M0922 ()
46M0922 Контроллер IBM ServeRAID M5014 SAS/SATA 46M0922 ()
Description:IBM ServeRAID M5014 PCI-e SAS/SATA RAID Controller for IBM System x ServersPart Number(s)
IBM Part# 46M0922
IBM Option Part# 46M0916
Overview:
The IBM ServeRAID M5014 SAS/SATA controller for IBM System x is the next generation 6Gbps SAS 2.0 RAID controller. This adapter has 2 internal mini-SAS connectors to control up to 32 devices and support global and dedicated hot-spare drives. The ServeRAID M5014 controller delivers a full-RAID 6 Gbps SAS 2.0 solution.
Specifications:
CategoryIBM Option
Sub-CategoryController
GenerationSAS/SATA PCIe
Part Number46M0922
Products ID461608
Controller TypeSerial ATA-300 / SAS 2.0
InterfaceSATA 3Gb/s / SAS 6Gb/s
Recommended Machine TypeServer
PlatformPC
Bus TypePCIe 2.0 x8
Data Transfer Rate600MB/s
Supported RAID LevelRAID 0 1 10 5
Form FactorPlug-in Card
Connector LocationInternal
Connector Type36 pin 4i Mini MultiLane SAS (SFF-8087)
Enlarge Image of Part# 46M0922
