726578-B21 HP H240ar 12G SP Int Smart HBA 726578-B21 ()

Description:HP H240ar 12Gb/s Single Port Internal Smart Host Bus Adapter Part Number(s) Option Part# 726578-B21 Overview: The HP H240ar Smart Host Bus Adapter comes in a Flexible Smart SAS HBA form factor that provides a reliable - high performing SAS connectivity to the data in the server internal drives. Supported on select Gen9 servers - it features eight internal physical links and it delivers 12 Gb/s SAS performance. The H240ar Smart Host Bus Adapter provides flexibility to run as an HBA mode or simple RAID mode. When operating in simple RAID mode - it provides RAID 0 - RAID 1 - and RAID 5 with optional HP Secure Encryption capabilities. Unlike the HP Smart Array Controllers - the H240ar does not offer any acceleration or support cache modules. Specifications: CategoryHP Option Sub-CategoryHost Bus Adapter GenerationH240ar Part Number726578-B21 Products ID725514 ManufacturerHP Device TypeSmart HBA-Storage Controller Host BusPCIe 3.0 x8 Controller Interface TypeSATA 6Gb/s SAS 12Gb/s Data Transfer Rate1.2GB/s RAID Level0, 1, 5 Supported DevicesHard Drive, Solid State Drive Channel Quantity8 Form FactorPlug-in Module Connector Type36 Pin 4i Mini MultiLane SAS (SFF-8087) Enlarge Image of Part# 726578-B21
