KTD4F Контроллер Dell PERC H710 512MB Mini Mono RAID KTD4F ()
KTD4F Контроллер Dell PERC H710 512MB Mini Mono RAID KTD4F ()
Description:Dell PERC H710 6Gb/s Mini Mono
RAID Controller with 512MB Nv Cache
For PowerEdge R320 R420 R520 R620 R720 R720XDR720XD
Part Number(s)
Dell Part# KTD4F
Dell Part# 0KTD4F
Overview:
The Dell™ PowerEdge™ PERC H710 RAID Controller is for select 12th Generation Dell Servers. The PowerEdge RAID Controller (PERC) H710 - with eight internal ports - delivers two PowerPC processor cores and a 72-bit DDR3 interface that drives 512 MB cache memory. This controller is designed to work in the dedicated proprietary expansion slot on PowerEdge Servers and does not fit the standard PCIe expansion slot. It has Dual Core PowerPC CPU which significantly increases IOPS performance with Cut-Through IO and Fastpath.
Specifications:
CategoryDell Controller
Sub-CategoryController
GenerationPCI-Express
Part NumberKTD4F
Products ID725782
Device TypeSerial Attached SCSI
Interface TypePCI Express 2.0 x8
Data Transfer RateUp to 6Gb/s per Port
Buffer512MB
Battery BackupYes
Connectors 2 x Internal mini-SAS SFF8088
RAID ControllerRAID 0 1 5 10 50 60
Enlarge Image of Part# KTD4F
