SYS-1029GQ-TVRT Сервер SYS-1029GQ-TVRT (SUPERMICRO)
SYS-1029GQ-TVRT Сервер SYS-1029GQ-TVRT (SUPERMICRO)
Краткое описание: SuperServer 1029GQ-TVRT (Black), Dual Socket P (LGA 3647), 12 DIMM slots, 1U Rackmount
brand_ice: SUPERMICRO
Co2 Savings: 544.06
Chassis type: Rack (1U)
Colour of product: Black
LED indicators: Activity, Power
On/off switch: Yes
Motherboard chipset: Intel® C621
Processor socket: LGA 3647 (Socket P)
Processor family: Intel® Xeon® Scalable
Number of processors supported: 2
Number of DIMM slots: 12
Supported memory types: DDR4-SDRAM
ECC: Yes
Hot-swap HDD bays: Yes
Storage drive sizes supported: 2.5"
RAID levels: 0, 1
Ethernet LAN: Yes
USB 3.0 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports quantity: 3
VGA (D-Sub) ports quantity: 1
Serial ports quantity: 1
Number of SATA III connectors: 4
Power supply: 2000 W
Redundant power supply (RPS) support: Yes
Number of redundant power supplies installed: 1
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 12.5 A
80 PLUS certification: 80 PLUS Titanium
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 10 - 35 °C
Operating relative humidity (H-H): 8 - 90%
Storage temperature (T-T): -40 - 60 °C
Depth: 894 mm
Height: 43 mm
Weight: 20.4 kg
Width: 437 mm
Sustainability certificates: RoHS
BIOS type: AMI
BIOS memory size: 32 Mbit
Harmonized System (HS) code: 84714100
brand_ice: SUPERMICRO
Co2 Savings: 544.06
Chassis type: Rack (1U)
Colour of product: Black
LED indicators: Activity, Power
On/off switch: Yes
Motherboard chipset: Intel® C621
Processor socket: LGA 3647 (Socket P)
Processor family: Intel® Xeon® Scalable
Number of processors supported: 2
Number of DIMM slots: 12
Supported memory types: DDR4-SDRAM
ECC: Yes
Hot-swap HDD bays: Yes
Storage drive sizes supported: 2.5"
RAID levels: 0, 1
Ethernet LAN: Yes
USB 3.0 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports quantity: 3
VGA (D-Sub) ports quantity: 1
Serial ports quantity: 1
Number of SATA III connectors: 4
Power supply: 2000 W
Redundant power supply (RPS) support: Yes
Number of redundant power supplies installed: 1
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 12.5 A
80 PLUS certification: 80 PLUS Titanium
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 10 - 35 °C
Operating relative humidity (H-H): 8 - 90%
Storage temperature (T-T): -40 - 60 °C
Depth: 894 mm
Height: 43 mm
Weight: 20.4 kg
Width: 437 mm
Sustainability certificates: RoHS
BIOS type: AMI
BIOS memory size: 32 Mbit
Harmonized System (HS) code: 84714100
Supermicro SYS-1029GQ-TVRT. Motherboard chipset: Intel® C621, Processor socket: LGA 3647 (Socket P), Processor family: Intel® Xeon® Scalable. Supported memory types: DDR4-SDRAM. Storage drive sizes supported: 2.5", RAID levels: 0, 1. BIOS type: AMI, BIOS memory size: 32 Mbit. Chassis type: Rack (1U), Product colour: Black, LED indicators: Activity, Power
1. Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
2. Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 12 DIMM slots
3. 4 PCI-E 3.0 x16 slots
4. 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays
5. Support 1x M.2 2242/2260/2280, Support M.2 SATA and NVMe
6. 2x 10GBase-T LAN ports via Intel X540
7. 7 Heavy duty 4cm counter-rotating
fans with air shroud & optimal fan
speed control
8. 2000W Redundant Power Supplies
Titanium Level (96%)
1. Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
2. Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 12 DIMM slots
3. 4 PCI-E 3.0 x16 slots
4. 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays
5. Support 1x M.2 2242/2260/2280, Support M.2 SATA and NVMe
6. 2x 10GBase-T LAN ports via Intel X540
7. 7 Heavy duty 4cm counter-rotating
fans with air shroud & optimal fan
speed control
8. 2000W Redundant Power Supplies
Titanium Level (96%)
