WS-C3650-48FS-L Переключатель WS-C3650-48FS-L (CISCO)
WS-C3650-48FS-L Переключатель WS-C3650-48FS-L (CISCO)
Краткое описание: Catalyst 3650-48FS-L Network Switch, 48 Gigabit Ethernet (GbE) PoE+ Ports, four 1 G Uplinks, 640WAC Power Supply, 1 RU, LAN Base Feature Set, Enhanced Limited Lifetime Warranty (WS-C3650-48FS-L)
brand_ice: CISCO
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Colour of product: Black
LED indicators: Yes
Market segment: Business
Country of origin: China
Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, GOST, NOM
Certification: 47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A) AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A KCC CNS13438 Class A EN55024 CISPR24 KN24
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: 1 GbE Copper
SFP module slots quantity: 4
Products per shipping (inner) case: 1 pc(s)
Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support: No
IP routing: Yes
Full duplex: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Auto MDI/MDI-X: Yes
Link aggregation: Yes
VLAN support: Yes
Number of VLANs: 4094
MAC address table: 32000 entries
Switching capacity: 176 Gbit/s
Jumbo frames support: Yes
DHCP features: DHCP server
Access Control List (ACL): Yes
IGMP snooping: Yes
SSH/SSL support: Yes
Multicast support: Yes
Memory type: DRAM
Internal memory: 4096 MB
Flash memory: 2000 MB
Noise level: 48 dB
Mean time between failures (MTBF): 383760 h
Redundant power supply (RPS) support: Yes
Number of power supply units: 1
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 106.98 W
Power plug type: Type C
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 48
Total Power over Ethernet (PoE) budget: 775 W
Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 96%
Operating altitude: 0 - 1500 m
Non-operating altitude: 0 - 5000 m
Width: 445 mm
Depth: 486 mm
Height: 44 mm
Weight: 7.8 kg
Package width: 520.7 mm
Package depth: 546.1 mm
Package height: 203.2 mm
Package weight: 2.2 kg
Bandwidth: 160 Gbit/s
Packaging content: WS-C3650-48FS-L Accessory Kit, 1 printed document
Quantity per pack: 1 pc(s)
Harmonized System (HS) code: 85176990
Products per master (outer) case: 1 pc(s)
brand_ice: CISCO
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Colour of product: Black
LED indicators: Yes
Market segment: Business
Country of origin: China
Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, GOST, NOM
Certification: 47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A) AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A KCC CNS13438 Class A EN55024 CISPR24 KN24
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: 1 GbE Copper
SFP module slots quantity: 4
Products per shipping (inner) case: 1 pc(s)
Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support: No
IP routing: Yes
Full duplex: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
Auto MDI/MDI-X: Yes
Link aggregation: Yes
VLAN support: Yes
Number of VLANs: 4094
MAC address table: 32000 entries
Switching capacity: 176 Gbit/s
Jumbo frames support: Yes
DHCP features: DHCP server
Access Control List (ACL): Yes
IGMP snooping: Yes
SSH/SSL support: Yes
Multicast support: Yes
Memory type: DRAM
Internal memory: 4096 MB
Flash memory: 2000 MB
Noise level: 48 dB
Mean time between failures (MTBF): 383760 h
Redundant power supply (RPS) support: Yes
Number of power supply units: 1
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 106.98 W
Power plug type: Type C
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 48
Total Power over Ethernet (PoE) budget: 775 W
Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 96%
Operating altitude: 0 - 1500 m
Non-operating altitude: 0 - 5000 m
Width: 445 mm
Depth: 486 mm
Height: 44 mm
Weight: 7.8 kg
Package width: 520.7 mm
Package depth: 546.1 mm
Package height: 203.2 mm
Package weight: 2.2 kg
Bandwidth: 160 Gbit/s
Packaging content: WS-C3650-48FS-L Accessory Kit, 1 printed document
Quantity per pack: 1 pc(s)
Harmonized System (HS) code: 85176990
Products per master (outer) case: 1 pc(s)
Cisco Catalyst 3650-48FS-L Network Switch, 48 Gigabit Ethernet (GbE) PoE+ Ports, four 1 G Uplinks, 640WAC Power Supply, 1 RU, LAN Base Feature Set, Enhanced Limited Lifetime Warranty (WS-C3650-48FS-L). Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 32000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
The Cisco Catalyst 3650-48FS-L Network Switch is a next-generation, enterprise-class access-layer switch that provides the foundation for full convergence between wired and wireless on a single platform. Standalone or stackable, this switch is built on the advanced Cisco StackWise-160 and takes advantage of the new Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC).
The Cisco Catalyst 3650-48FS-L Network Switch is a next-generation, enterprise-class access-layer switch that provides the foundation for full convergence between wired and wireless on a single platform. Standalone or stackable, this switch is built on the advanced Cisco StackWise-160 and takes advantage of the new Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC).
